Model

SY604S

Horsepower

60    HP

Dimensions

Length    2800mm Width 1550mm Height 1850m

Track    size

Length    350*90*54 Width 350mm
     The    track has a full outer diameter of 150, an inner diameter of 80, a chassis    height of 43, and a power output of 65.

Diesel    Engine Brand

XINCHAI     engine

Engine    speed

2400    rpm backfilling soil width 1m

Whole    machine weight

1600    kgs

Fuel    consumption

About    3-4  liter/mu

Walking    speed

The    fastest 10 KM/h

Gearbox

Patented custom gearbox

Gear

4 forward gears, one reverse gear, divided    into high and low speed, a total of 10 gears

track

The crawler has strong grip ability,    suitable for harsh terrain operations, small turning torque, flexible    turning, and can be used for both water and drought

air    filter

Paper filter, clean the air filter after    each work, blow the dust inside

Water    tank

After receiving the machine, check whether    there is water in the water tank. There should be no shortage of water in the    water tank. When it is cold, add antifreeze.

Transmission mode:

 drive shaft transmission, hydraulic    transmission, not mechanical

Rotary    tillage

Rotary    tiller width 1m, rotary tiller blade length 1950mm

weeding

Weeding    width 1m scraping the ground and weeding

Backfill

Soil    width 1m

Ditch

The    trench width is 30cm, the depth is 30cm

Bulldozer

Shovel    width 1m high 30cm, maximum ground clearance 25cm

efficient

Normally    about 1-2 acres/hour

Additional    implements:

 Compatible with all wheel tractor implements
