Product Details

The Small Articulated Tractor is a versatile agricultural machinery designed for various farming and horticultural operations. With a compact size and powerful performance, this tractor is equipped with a diesel engine that typically delivers power ranging from 24.5 to 100 horsepower, making it suitable for small to medium-sized farms, orchards, greenhouses, and horticultural applications .The articulated design is the key feature of this tractor, connecting the front and rear sections through a pivot joint. This allows for an exceptionally small turning radius, making it highly maneuverable in tight spaces and irregularly shaped fields . The tractor's compact dimensions and lightweight construction (typically between 1 to 2 tons) make it ideal for operations where larger tractors would be impractical or damaging to the soil.

With a wheelbase typically around 5'5" (1.65 meters) and a width of approximately 64 inches (162.5 cm), these tractors offer excellent stability while maintaining the ability to operate in tight quarters . The ground clearance of around 11.5 inches (29 cm) ensures that the tractor can traverse rough terrain without getting stuck or damaging vital components .The articulated steering mechanism is the defining feature of this tractor. Unlike conventional tractors that turn by pivoting the front wheels, the articulated design allows the entire front section of the tractor to pivot relative to the rear section, creating an exceptionally tight turning radius of just 8'0" (2.44 meters) . This allows the operator to make U-turns in extremely limited space, significantly reducing the time and effort required to maneuver in small fields or between rows of crops .

Product advantages

The 9x3 gear configuration provides 9 forward gears and 3 reverse gears, allowing the operator to accurately match the tractor's speed with the task at hand. A 3-speed static hydraulic transmission that allows for continuously variable speed, achieving smooth acceleration and deceleration without the need for clutch pedals. The premium model is equipped with a 12F+12R power shift gearbox, allowing the operator to shift gears without using the clutch, improving productivity during repetitive tasks. Synchronous transmission, which uses a synchronous ring to match the speed of the input and output shafts before meshing gears, provides smooth and easy shifting.The small articulated tractor offers significant productivity advantages over larger agricultural machinery. The tractor's compact size and maneuverability allow it to work more efficiently in small fields and between rows of crops, reducing the amount of time spent on non-productive activities .The powerful engine and efficient transmission system ensure that the tractor can maintain consistent performance throughout the workday. Users have reported that these tractors can complete in one and a half days what would take three days with smaller machines, while actually saving fuel in the process . The fuel efficiency is particularly impressive, with some models achieving up to 40% better fuel economy than traditional tractors of similar power .The hydraulic system's quick response time and high lift capacity allow for faster implement changes and more efficient operation of agricultural equipment.

Model	SY504
Horsepower(hp)	50
Type	4 ×4 Wheeled tractor
Overall dimension(mm)
Length	2850
Width	1350
Height	2000(Cab top 2300mm)
Tread(mm)
Front Wheel	1100
Rear Wheel		1200

Wheel base(mm)	1512
Ground Clearance(mm)	266
Structure weight(kg)	1360 (cabin 1560kg)
Front Wheel ballast(kg)	48
Rear Wheel ballast(kg)	50
Engine
Type	vertical, water cooled, four cylinder,four stork
Rated rev. (r/min)	2400
Rated power (KW)	36.8
Clutch	Dry-friction,single- stage
Transmission system
Gearbox	(4+1)X2 ,8F+2R shifts
Central transmission	Gear sector
Tractor brake	Dry brake,discs
Tyre
Front wheel	6.00-12/6.50-16
Rear wheel	9.5-24/11.2-24
PTO shaft rev.	540/720 r/min
